Etiketten Drucker – Einsteigermodell

PXB23308

Eigenschaften
  • PXB23308 with USB interface, nice quality with competitive price. It can be widely used in shop, business logistics field
  • Support variety printing paper, including thermal paper roll, paper label, and adhesive paper
  • Support 20mm-60mm paper width
  • The print head with adjustable pressure
  • Automatic paper checking function
  • Temperature adaptive control
Technische Details
Printing method Thermal barcode Thermal receipt
Printing speed 101mm/s(Max), 50.8mm/s(Min) 90mm/s
Paper width 20mm~60mm
Printing width 56mm(Max) 48mm
Column capacity 8 dots/mm(203 DPI) 384 dots/line
Paper diameter 80mm
Interface USB
Bar code CODE128, EAN128, ITF, ITF25, CODE39, CODE39C, CODE39S, CODE93, EAN13, EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR, POSTNET, UPC-A, UPCA+2, UPCA+5, UPCE, UPCE+2, UPCE+5, MSI, MSIC, PLESSEY, ITF14, EAN14
2-Dimensional PDF417, QR CODE, DATA MATRIX
Power adaptor DC 12V / 3A
Cash drawer output DC 12V / 1A
Weight 1.08KG
Dimensions 206×136×148 (D×W×H)
Technische Dokumente

Hier bekommen Sie technische Unterlagen zum Download:
