| Print method |
Thermal transfer |
| Printing Resolution |
203 dpi |
| Print Speed |
4 ips (101.6 mm/s) |
| Interface |
USB DEVICE 2.0 |
| Max Printing Width |
4.25″ (108 mm) |
| Max Printing Length |
157″ (4000 mm) |
| Memory |
8 MB FLASH ROM, 16 MB SDRAM |
| Media |
Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain paper or thermal paper
Width: 4.37″ (111 mm) max., 0.98″ (25 mm) min
Supply roll: OD 8″ (203.2 mm) max., ID 1″ (25.4 mm) min
Thickness: 0.003″ – 0.007″(0.08 – 0.18 mm), including liner |
| Ribbon |
Wax, Wax/Resin, Resin
Ribbon roll: OD 2.68″ (68 mm) max., ID 1″ (25.4 mm) core
Max width: 110 mm; Max length: 300 m. Ink side: Out |
| Media Sensor |
Reflective (Adjustable)/ Transmissive |
| Fonts |
Five built-in ASCII fonts, Downloadable TrueType fonts |
| Barcode Types |
1D Barcode: Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC A/E 2
and 5 add-on, EAN-13/8/128, UCC-128
2D Barcode: MaxiCode, PDF417, Datamatrix, QR Code |
| Operating Environment |
Temperature: 0℃ – 40℃ (32°F ~ +104°F); Relative humidity: 5% – 85% non condensing |
| Storage Environment |
Temperature: -40℃ – 60℃ (-40°F ~ +140°F); Relative humidity: 5% – 85% non condensing |
| Power Rating |
Input: AC 100~240 V, 50/60 Hz
Output: DC 24 V, 2.5 A |
| Dimensions |
W 9.53″(242 mm) × D 9.86″(250.5 mm) × H 7.83″(199 mm) Media compartment stored
W 9.53″(242 mm) × D 13.7″(348.5 mm) × H 7.83″(199 mm) Media compartment withdrawn |
| Weight |
2.8 kgs |
| Optional Items |
Wi-Fi, Bluetooth, RFID 10/100 MB Ethernet, Rotary Cutter, Peeler, External Rewinder Rewinder |
|
|
