| System |
|
| Chipset |
Intel Bay Trail-D J1900 |
| CPU |
Intel J1900 Quard-Core 2.0GHz, 2M
Fanless/10W |
| Memory |
4GB DDRIII , 1 x DDRIII 1333 DIMM |
| Storage |
MSATA 128GB SSD |
| Ethernet Card |
Realtek 8103EL 10/100M Support diskless boot |
| Front Display |
| Panel |
15″ TFT LED |
| Brightness/Contrast |
450 cd/m² / 700 : 1 |
| Resolution |
1024×768 |
| Touch Screen |
True-flat capacitive touch |
| I/O PORTS |
|
| Serial/Parallel Port |
3x RS232 |
|
| USB |
6 x USB 2.0; 1x USB 3.0 |
| LAN |
1 x RJ45 10/100/1000M |
| Audio Jack |
1 x Mic in & SPK out |
| Support OS |
|
| Windows / Linux |
Windows XP, POS Ready 2009, Windows 7/8/10, POS Ready 7, Unbuntu 13.04 LTS |
| Optional Accessoires |
|
| Card Reader |
1&2&3 Magnetic Stripe Reader, RFID, I-Button |
| Customer Display |
LED/VFD |
| 2nd Display |
9.7” LED Monitor |
| Wireless Module |
802.11 a/b/g/n |
| Fingerprint Scanners |
optional |
| Environmental |
|
| Operating / Storage Humidity |
20% – 80% / 20% – 80% |
| Operating / Storage Temperature |
0°C – 40°C / -20°C – 60°C |
| Power Consumption |
60W (max.) |
| Packing Information |
|
| Carton Size |
500x300x470mm |
| Net / Gross Weight |
6,5KG / 6,8KG |
